Aluminum Cooling Fan 16000rpm 40x40mm 5V-8V conector Bec Fussion FS-PF40S
The Fussion 40x40x10mm Aluminum High Speed HV Cooling Fan is an excellent choice for keeping drive or motor temperatures in check.
Essential Accessories
Recommended Products
The Fussion 40x40x10mm Aluminum High Speed HV Cooling Fan is an excellent choice for keeping drive or motor temperatures under control.
The fan features a 7075 CNC machined aluminum housing that helps dissipate heat, allowing cooler operation of the fan motor. Additionally, the aluminum frame adds strength to the assembly, helping to protect the fan blades in the event of a crash.
The JST connector is practical and fast, easy to install, easy to use, the wiring has positive and negative poles, the wrong connection will not work.
Note:
This fan should be installed at least 5mm from the motor to allow sufficient airflow and avoid interference from magnets.
Specifications:
- Material: T6 aluminum case with plastic fan
- Color: Silver - Black
- Size: 40x40x11mm
- Mounting pattern: 32x32mm
- Weight: approx. 24gr.
- Voltage range: HV 5V - 8.75V Max.
- Current: 0.65A
- Maximum speed: 16000rpm
- Connector: JST (Bec)
- Cable Length: 16cm approx.
